VCC Ducted - ActronAir

Efficiency, Innovation and Adaptability as Standard

Explore the ActronAir VCC Series, our intelligently-designed rooftop package that delivers reliable performance and energy efficiency combined with flexible installation and easy commissioning, to make it the ideal choice for commercial applications. The array of intuitive controls offer simplicity of system management – both during installation and for day-to-day maintenance – as well as enhanced, year-round user comfort.

Capacities:

3 Phase
15.0kW, 17.0kW, 19.0kW,

21.0kW, 29.0kW, 33.0kW,

72.0kW, 85.0kW, 96.0kW

Compressor:

Variable Speed Compressor

Operating Range:

From -10ºC – 57ºC

Product Features

Consistent
Comfort

Adaptive
Defrost Logic

Turbo Mode

Energy
Efficiency

Commissioning
tool (BCT)

Louvred
Grille Guard

Foil-Faced
Insulation

Exceptional Performance

Tru-Inverter Technology and Inverter compressors work together to deliver optimal performance, reduced energy consumption and lower operating costs.

Advanced Technology

Innovative components, including VSD drives and EC plug fans, ensure enhanced comfort, quieter operation and adaptability to changing cooling and heating needs.

Intuitive Controls

With a range of advanced options, including our award-winning NEO controller and remote monitoring via Modbus BMS, optimal user-experience is guaranteed.

Flexible Design

Offering up to 32 handing configurations, interchangeable panels and a wide operating range, the VCC Series is perfect for a variety of different applications.

Convenient Commissioning

Simplified set-up via the Bluetooth Commissioning Tool (BCT) paired with ActronLink streamlines the configuration process and reduces installation time.

* available as a standard inclusion for 72-96kW range and can be purchased separately for the smaller capacities.

Performance

Enhanced Capacity Flexibility, with Tru-Max

The ability of Tru-Max Functionality to exceed rated capacity by up to 10% means that the rooftop package unit can adapt to different building demands and environmental conditions as well as unexpected peaks, to ensure consistent temperature and humidity control, and keep everyone comfortable. This flexibility translates into reduced need for maintenance, more economical operation, and cost savings for the end user.

Low Ambient Cooling

Our Low Ambient Cooling feature provides cooling even at low outdoor temperatures, down to +5 degrees Celsius. This is especially valuable in environments that require cooling due to high internal heat loads from equipment, people, or other sources.

Reliable, Wide Operating Range

Operating effectively and efficiently in outdoor temperatures ranging from -10°C to 57°C makes the unit suitable for a wide range applications in every part of Australia – whatever our unique weather decides to serve up.

Super-Efficient EC Plug Fans

EC plug fans reduce the fan speed to precisely match the specific airflow requirements of the system. Compared to belt-driven fans, they achieve an efficiency increase of up to 50%, and compared to AC fans, they achieve a 20% efficiency increase.

Quiet, Efficient Condenser EC Fans

Condenser EC fans are designed to deliver quieter performance as well as precise control of fan speed and airflow. This improves energy efficiency by reducing power consumption to meet current cooling demands, resulting in lowering operating costs.

Enhanced Corrosion Resistance

The Hydrophilic Blue Fin coating provides a protective barrier for both indoor and outdoor coils, significantly reducing the risk of corrosion caused by exposure to harsh environmental conditions and Australia’s challenging and diverse climates.

Quiet Mode

Quiet Mode reduces the noise produced during cooling or heating by lowering the speed of the compressor and outdoor fans by up to 4db lower than normal, without compromising indoor comfort. It's ideal for environments such as offices, hotels, schools, or residential areas.

Adaptive Defrost Logic

This feature detects ice formation on the outdoor coil during heating. If the temperature drops below -5 degrees Celsius or pressure falls unusually low, it activates a defrost cycle. This is crucial for maintaining efficient heat exchange and preventing performance degradation due to ice accumulation.

Turbo Mode

Turbo Mode rapidly cools or heats a space by operating the system at maximum capacity for 30 minutes to reach the desired temperature. Once the 30-minute period elapses, the system automatically returns to the pre-established settings, ensuring a smooth transition.

Powered by Tru-Inverter Technology

Tru-Inverter Technology allows the compressor to adjust its speed according to the cooling or heating needs of a space.

Unlike traditional fixed-speed systems that cycle on and off, Tru-Inverter Technology ensures precise load adjustment, improving energy efficiency, reducing energy consumption, and maintaining consistent indoor comfort.

Energy Efficiency

Adjusting the compressor's speed avoids the high energy spikes associated with startup and shutdown cycles, making the operation more efficient and environmentally friendly.

Cost Savings

This dynamic adjustment means the system only uses the necessary amount of energy, significantly reducing energy consumption and lowering utility bills.

Consistent Comfort

The precise control of the inverter compressor ensures a consistent and comfortable indoor environment and reduces unnecessary temperature fluctuations.

Save with Part-Load Operation

With inverter compressors and True-Inverter Drive Technology combined, the system can operate efficiently at reduced capacities (part load). This is ideal for commercial settings, where units often run below full capacity during off-peak periods. It improves energy efficiency, reduces operating costs, and maintains consistent indoor comfort while extending the lifespan of the equipment.

VCC can deliver substantial power consumption savings, up to 30%, when operating at part load.

Energy Efficiency

Seasonal Energy Efficiency (SEER)

SEER is a measurement of energy efficiency of units across various temperatures and load conditions. Units with high SEER ratings provide greater cooling output while using less energy, making them ideal for operating in different climate zones and supporting sustainable, cost-effective building operations.

Up to 32 Handing Configurations

VCC provides up to 32 different handing configurations, allowing for customised solutions to meet specific building requirements. This versatility ensures optimal performance, easier installation, and adaptability to a wide range of applications, enhancing compatibility and reducing installation costs.

Double-Slopped Main Drain Tray*

The double-slope design of the drain tray ensures more effective drainage of condensate, preventing water accumulation and reducing the risk of overflow or leaks. This improves indoor air quality, reduces maintenance needs, and ensures reliable operation, especially in humid conditions.
* Applicable on some models

Foil-Faced Insulation for greater efficiency

25mm Foil-Faced Insulation aids with improving energy efficiency by reducing heat gain and loss. It also resists mould and mildew, thus promoting healthier indoor air quality and providing durable, long-lasting performance.

* Applicable on some models

Interchangeable Panels*

Having interchangeable panels on site means easier configuration of front and side panels during installation, providing greater flexibility to fit specific site requirements. This feature can help minimise installation downtime, reduce costs and ensure a smooth and efficient setup.

* Applicable on some models

Louvred Grille Guard for Extra Protection

By shielding the unit from environmental impacts, the louvered grille guard extends the lifespan of the unit, reducing the need for repairs or replacements caused by weather-related damage.

Pull-Out Filter Tray for Ease of Maintenance*

The tray can easily be removed without the need for screws, making filter access quick and straightforward. This simplifies routine maintenance and cleaning, saving time and effort.

* Applicable on some models 
* Filters not included 

Simpler Commissioning with ActronLink

The tool provides contractors with an intuitive interface accessible from a handheld device, making configuration straightforward and accessible on-site. By streamlining the commissioning process, ActronLink helps reduce overall installation time, minimising disruptions and allows the system to be up and running faster.

* available as a standard inclusion for 72-96kW range and can be purchased separately for the smaller capacities.

Controls

A Choice of Controllers

A range of controllers for VCC units are available, providing flexibility to meet various commercial needs. Options include remote monitoring and integration with building management systems (BMS), enhancing efficiency, energy management, and ease of use.

Bluetooth Commissioning Tool (BCT)*

Using Bluetooth connectivity, BCT makes it easier to configure larger 72-96kW VCC units, particularly when site-specific adjustments are required, saving time and physical effort. It not only streamlines the setup process, it also helps simplify maintenance and fault finding throughout the system’s lifecycle.

* Standard inclusion on 72-96kW VCC units

Hot Water Heat reclaim
(Desuperheater)*

This optional feature efficiently recycles excess heat from the HVAC system to rapidly heat water, enhancing energy efficiency, reducing costs, and supporting eco-friendly practices by minimising waste and lowering carbon emissions.

* Available as an option, request a quote.

Economiser with Spill Air

By using cooler outside air instead of running the compressor, when conditions allow, the Economy Cycle significantly reduces energy consumption, leading to lower operating costs, all while maintaining consistent comfort and supporting sustainability practices.

* Available as an option, request a quote.
